Name: Belden Glass Braided Silicone Rubber Cable – 180°C
Brand: Advanced Thermal Supplies
Price: 0.01 AUD
Availability: InStock

Belden Glass Braided Silicone Rubber Cable 180°C on black plastic spool with black silicone rubber jacket, fibreglass braided insulation and exposed tinned copper stranded conductor for high-temperature industrial wiring.

High Temperature Electrical Cable

Belden Glass Braided Silicone Rubber Cable – 180°C
Tinned Copper, Fibreglass Braided High-Temperature Cable (0.6/1.1kV)

Belden Glass Braided Silicone Rubber Cable is a high-temperature electrical cable manufactured with a tinned copper stranded conductor, silicone rubber insulation and a durable glass braided fibreglass jacket. Rated for continuous service up to 180°C with a 0.6/1.1kV voltage rating, it is designed for demanding industrial environments requiring excellent heat resistance, flexibility and mechanical protection.

Common Applications

Industrial ovens and furnaces
Heating equipment and process machinery
Electric motors and generators
Steel mills and foundries
Glass manufacturing equipment
High-temperature industrial wiring

Specifications

Temperature Rating	180°C
Voltage Rating	0.6/1.1kV
Conductor	Tinned Copper
Insulation	Silicone Rubber
Outer Jacket	Glass Braided Fibreglass
Roll Length	100 metre rolls up to 10mm² 50 metre rolls for 16mm²–95mm²
Available Colour	Black
Applications	Industrial furnaces, ovens, heaters, motors, generators and high-temperature electrical equipment.

Available Sizes

Size	Outside Diameter	Current Rating
2.50mm²	3.7mm	58 Amp
4.00mm²	4.6mm	77 Amp
6.00mm²	5.7mm	95 Amp
10.0mm²	7.6mm	135 Amp
16.0mm²	9.2mm	185 Amp
25.0mm²	11.4mm	250 Amp
35.0mm²	12.6mm	310 Amp
50.0mm²	15.0mm	390 Amp
70.0mm²	17.0mm	500 Amp
95.0mm²	19.5mm	600 Amp
