Rigid Laminate Sheets

Cogetherm Mica P&M Laminate
High-Temperature Electrical & Thermal Insulation

Cogetherm Mica P&M rigid laminate is a high-performance mica-based insulation material designed for demanding thermal, electrical, and mechanical applications. We commonly supply Cogetherm M and Cogetherm P grades, allowing selection based on the temperature and performance requirements of the application. These rigid laminates provide strong dielectric performance, low thermal conductivity, and good mechanical stability in environments where conventional insulation materials may not be suitable.

• Grades Commonly Supplied: Cogetherm M and Cogetherm P
• Available Thicknesses: 0.2mm, 0.4mm, 0.5mm, 0.8mm, 1mm, 1.5mm, 2mm, 2.5mm, 3mm, 5mm, 6mm, 8mm, 10mm, 12mm, 15mm, 20mm, 25mm
  (Standard thicknesses listed — custom thicknesses also available on request via the quote form)
• Temperature Resistance: Continuous: 500 °C (M) / 700 °C (P); Peak: 700 °C (M) / 1000 °C (P)
• Sheet Dimensions: 1000mm x 1000mm
• Supply Format: Available as full sheets, cut panels, or CNC machined parts to your drawings

Key Benefits

• Excellent thermal and electrical insulation performance
• High mechanical strength and dimensional stability
• Low thermal conductivity with good resistance to heat
• Resistant to oils, grease, moisture, and many industrial chemicals
• Suitable for demanding industrial insulation and heat barrier applications

Cogetherm Mica P&M is used across a wide range of high-temperature and electrically demanding applications, including furnace and induction equipment, high-voltage insulation components, industrial thermal barriers, press tooling, and other applications requiring long-term stability under heat and load.

This product is available as raw laminate sheets and cut panels or fully fabricated CNC machined components to suit your application.

For higher electrical insulation strength at lower temperatures, explore our G10 Epoxy Laminate.

Request A Quote - Cogetherm Mica P&M
