HIGH TEMPERATURE BLANKET, CLOTH OR PAPER

EV Fire Blanket – High-Temperature Fire Containment for Electric & Hybrid Vehicles
Extreme Heat Resistance & Smoke Containment for EV Safety

Designed for Extreme Fire Protection

• Contains high-temperature EV and hybrid vehicle fires
• Withstands thermal applications up to 1200°C with a melting point of 1600°C
• Reduces toxic smoke and fire spread
• Includes long handles for easy deployment and a robust storage bag for accessibility

Features:

• High-Performance Material: Made from high-grade silica fabric with a Graflex graphite finish
• Heavy-Duty Construction: Stitched with stainless steel and meta-aramid sewing thread
• Durable Storage: Packed in a heavy-duty PVC-coated polyester bag with a water-repellent finish
• Easy Handling: FR webbing straps (4 or 6) for secure use and storage

Specifications:

• Finish: Graflex
• Weave: 8-H Satin
• Thickness: 0.7 mm
• Tensile Strength: Warp – 2000 N/50 mm, Weft – 1200 N/50 mm
• Silica Content: 95% minimum

Available Sizes & Uses:

• 3.0 m × 4.0 m – 8.7 kg (9.17 kg with bag), Packed size: L65 cm, H20 cm, D30 cm
  Suitable for electric scooters, e-bikes, motorcycles, and small battery systems.
• 6.0 m × 8.0 m – 31.24 kg (32 kg with bag), Packed size: L75 cm, H35 cm, D45 cm
  Suitable for passenger EVs, SUVs, and light commercial vehicles.

Storage & Deployment:

• Rolled and packed in a heavy-duty bag with a drawstring fastener and carry handles

Applications:

• EV charging points
• Underground and multi-storey car parks
• Car workshops and showrooms
• Service areas and filling stations
• Car ferries and rail services
• Fire, emergency, and recovery services

For other high-performance heat protection fabrics, see our Silica Cloth – Up to 982°C.

Request A Quote - EV Fire Blanket
